Total Room Flooding System in Delhi NCR
A total room flooding system fills an entire closed room with a fire suppression agent, so a fire is put out wherever in that room it starts. The agent can be FM-200, FK-5-1-12, an inert gas or CO₂. It protects server rooms, UPS rooms, panel rooms and archives, and it only works if the room is well sealed.
When a room is full of things that can start a fire, such as racks, panels, batteries or shelves of files, you cannot guess where the fire will begin. Room flooding does not try to guess. It treats the whole volume of the room as one space and fills all of it. The calculation behind it is simple in idea but needs care: get the room volume or the sealing wrong and the gas will not stay long enough.
Where is the Total Room Flooding System used?
- Server and network rooms
- UPS and battery rooms
- Electrical and panel rooms
- Archives and record rooms
- DG and transformer rooms (CO₂)
- Control rooms
- Telecom rooms
- Storage rooms with high-value stock
How does the Total Room Flooding System work?
We work out the amount of agent from the room volume, the lowest temperature the room sees and the type of fire risk. Detectors go on the ceiling, and in the false floor and false ceiling if cables run there. When two detectors confirm a fire, the panel sounds a warning, shuts the AC and dampers if they are linked, and then releases the agent through nozzles spread across the room. The room must hold the agent for a set time, which is why we seal openings and may suggest a door fan (integrity) test.
Total Room Flooding System at a glance
| Agents | FM-200, FK-5-1-12, inert gas or CO₂ |
|---|---|
| Design basis | Room volume, risk and lowest expected temperature |
| Detection | Cross-zoned smoke detectors, including floor and ceiling voids |
| Controls | Pre-discharge alarm, abort switch, manual release, hold switch |
| Room integrity | Openings sealed; integrity (door fan) check recommended |
| Interlocks | AC shut-off, damper closing, door holders |
| Reference standards | NFPA 2001 (clean agents); NFPA 12 (CO₂) |
Which agent for total flooding?
| FM-200 / FK-5-1-12 | Inert gas | CO₂ | |
|---|---|---|---|
| People in the room | Yes, at design level | Yes, at design level | No |
| Cylinder space | Small | Large | Medium |
| Discharge time | About 10 s | About 60 to 120 s | About 60 s |
| Typical room | Server, UPS, control | Large server halls, archives | DG, transformer, plant |
Each agent has its own page if you want the detail: FM-200, clean agents and CO₂ flooding.
How we work, step by step
- Site visit: We come and see the space ourselves, measure it, and look at what is likely to catch fire, how air moves, where the gaps are and where power comes from.
- Design: We pick the agent, size the system and send you a simple layout with quantities, so you know exactly what you are paying for.
- Supply: Cylinders, detectors, nozzles, pipes and the panel arrive as per the design you approved, nothing swapped quietly.
- Installation: Our team fits and wires everything. In live sites we plan the noisy work around your working hours.
- Testing: Before we call it done, we test detection, alarms, the release circuit and pressures, and show you the results.
- Handover: We walk your staff through the alarms, the abort and manual release, and what to do if the system ever goes off.
- AMC: After that, regular visits keep it ready. A system that is never checked is a system you are hoping works.
What we check on AMC visits
- Cylinder pressure and agent weight check
- Detector, panel, abort and manual release tests
- Interlock tests (AC shut-off, dampers)
- Room sealing check after any new cable or duct work
- Nozzle and pipe inspection
- Refilling and recommissioning after a discharge
- Service report
A very common problem in older rooms is new cable holes that nobody sealed. The AMC sets how often we check, and you can call us any time something in the room changes.
You may also need
- Server Room Fire Suppression
- FM-200 Fire Suppression System
- CO₂ Flooding System
- Fire Alarm System Installation
- Guide: FM-200 vs CO₂ vs clean agent
Send us the room size (length, width, height) and a few photos. Call or WhatsApp +91 85870 53556, or send an enquiry.
Design, testing & support
Total room flooding systems with clean agent or CO₂ for server rooms, UPS rooms, panel rooms and archives across Delhi NCR.
Site-specific design
Each system is sized for the room, panel, kitchen, building or vehicle it protects.
Tested at handover
Every installation is tested and commissioned before handover.
- Free site survey across Delhi NCR.
- System chosen for your actual fire risk.
- Protects equipment, people and operations.
- Reduces downtime and repair costs.
- Professional installation, testing and commissioning.
- Regular inspection, maintenance and AMC services.
Everything you need to know about Total Room Flooding System in Delhi NCR
A fixed system that fills a whole closed room with a suppression agent, so a fire anywhere in the room is put out.
The agent has to stay in the room at the right level for several minutes. If it leaks out through gaps, the fire can come back.
A test with a fan fitted in the doorway that measures how fast air leaks out of the room. It tells you whether the room can hold the gas long enough.
With clean agents, yes, at the design level, though people should still leave when the alarm sounds. With CO2, nobody should be inside.
Ye room ki lambai, chaudai, unchai, temperature aur kaunsa agent use hoga, is par depend karta hai. Site visit ke baad hum exact calculation dete hain.
Yes. If cables run there, we add detectors and nozzles in those voids as well.
